Rated Line Pull
2,500 lbs (1,134 kg) Max
Gear Train System
Planetary Gear
Reduction Ratio
249:1
Motor
3 Hp (2.25 Kw) 12 Volt DC
Winch Line
3/16" x 50' (4.76 mm x 15.24 m) Cable
Overall Dimensions
13.8" x 4.5" x 4.5"
(350 x 114 x 114 mm)
(350 x 114 x 114 mm)
Bolt Pattern
5" x 3" (48 x 76 mm)
Shipping Weight
36 lbs (16.4 kg)
| Line Pull | Line Speed | Motor Current | ||
|---|---|---|---|---|
| Lbs | Kgs | Fmp | Mpm | Amp |
| 0 | 0 | 19.7 | 6 | 31 |
| 1000 | 454 | 18.4 | 5.6 | 105 |
| 2000 | 907 | 14.8 | 4.5 | 145 |
| 2500 | 1135 | 13.5 | 4.1 | 195 |
| Cable Layer | Rated Line Pull | Cable Capicity | ||
|---|---|---|---|---|
| Lbs | Kgs | Ft | Meters | |
| 1 | 2500 | 1135 | 9.2 | 2.8 |
| 2 | 2130 | 967 | 20.3 | 6.2 |
| 3 | 1855 | 842 | 33.1 | 10.1 |
| 4 | 1643 | 746 | 39.4 | 12 |
| 5 | 1475 | 669 | 50 | 15 |
